ホーム > 製品情報 > 単一出力スイッチング電源 > 25W AC / DC単一出力12V 2A電源LEDドライバ

基本情報

モデル:  MWNES-25-2

製品の説明

モデル番号:MWNES-25-2保証:> 2年入力電圧:15V起動モード:自励式スイッチング電源電源供給システム:ターミナル配電装置変調システム:PFAWブランド:Omwo仕様:159 * 98 * 38mm HSコード:8504401990出力タイプ:単一出力電力:1 - 50W接続モード:シリーズスイッチング電源電圧調整モード:周波数変調タイプエネルギー伝送:双方向伝送認証:CE、UL、RoHS、ISO、CCC、CB、CSA商標:OMWO原産地:浙江省特徴:
・Meanwell 12V 2A電源
・ユニバーサルAC入力/フルレンジ
・保護:短絡/過負荷/過電圧
・自由空気対流による冷却
・100%全負荷バーンインテスト
・2年間の保証
モデルシリーズ:

NES-25-5 / NES-25-12 / NES-25-15 / NES-25-24 / NES-25-48



詳細:
MODEL NES-25-12
OUTPUT DCVOLTAGE 12V
RATEDCURRENT 2.1A
CURRENtrANGE 0~2.1A
RATEDPOWER 25.2W
RIPPLE & NOISE (max.) 120MVP-P
VOLTAGEADJ.RANGE 10.8~13.2V
VOLTAGE TOLERANCE ±1.0%
LINEREGULATION Note4 ±0.5%
LOADREGULATION ±0.5%
SETUP.RISEHOLD.TIME 500ms, 30ms/230VAC 1200ms, 30ms/115VAC at full load
HOLD TIME(TYP.) 50ms/230VAC   10ms/115VAC at full load
INPUT VOLTAGERANGE 85~264VAC 120~370VDC
FREQUENCYRANGE 47~63HZ
EFFICIENCY (Typ.) 83%
AC CURRENT (Typ.) 0.55A/115VAC    0.35A/230VAC
INRUSH CURRENT (Typ.) COLD START 45A
LEAKAGECURRENT <2mA/240VAC
PROTECTION OVERLOAD 110 ~ 150% rated output power
Protection type: Constant current limiting, recovers automatically after fault condition is removed
OVER VOLTAGE 13.8~16.2V
Protection type: Shut down o/p voltage, re-power on to recover
OVER TEMPERATURE U1 TJ 140 typically (U1) detect on main control IC
Protection type: Shut down o/p voltage, recovers automatically after temperature goes down
ENVIRONMENT WORKING TEMP -20~+60°C (refer to output load derating curve)
WORKINGHUMIDITY 20~90% RH non-condensing
STORAGE TEMP HUMIDITY -40~+85°C  10~95%RH
TEMPCOEFFICIENT ±0.03%(0~45°C)
VIBRATION 10~500HZ,2G10min/1cycle,60 min each alongX,Y,Zaxes
SAFETY & EMC SAFETY STANDARDS U60950-1, CB(IEC60950-1) approved
WITHSTAND VOLTAGE I/P-0/P:3KVAC   I/P-FG:1.5KVAC    0/P-FG:0.5KVAC
ISOLATIONRESISTANCE I/P-0/P,I/P-FG,0/P-FG:100M Ohms/500VDC
EMC EMMISION Compliance to EN55022(CISPR22)classB,  EN61000-3-2,-3
EMC IMMUNITY Compliance to EN61000-4-2,3,4,5,6,8,11 ENV50204,EN550204,EN61000-6-1, Light industry level criteriaA
QTHERS MTBF 411.47Khrs min. MIL-HDBK-217F (25 °C)
DIMENSION 99*80*35mm(L*W*H)
PACKING 0.3Kg; 45pcs/14.5Kg/0.66CUFT
NOTE 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25°C of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. Line regulation is measured from low line to high line at rated load.
5. Load regulation is measured from 0% to 100% rated load.
6. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives.
25W AC to DC Single Output 12V 2A Power Supply LED Driver25W AC to DC Single Output 12V 2A Power Supply LED Driver25W AC to DC Single Output 12V 2A Power Supply LED Driver25W AC to DC Single Output 12V 2A Power Supply LED Driver25W AC to DC Single Output 12V 2A Power Supply LED Driver25W AC to DC Single Output 12V 2A Power Supply LED Driver
